PCB Router PCB Depaneling Equipment with Upper Vacuum Cleaner
The best sulotion for PCB depaneling
- Avoids problems such as the tin break and damage to the compnent caused by manually bending a plate
- Avoids the stress produced mechanically by using punch or bending
- Suitable for cutting of a circle, arc and line of a finished plate
Rotational speeds adjustable
- The spindle head consists pf a high-speed motor and the main shaft, which can be replaced separately to reduce the cost of maintenance
- The high-speed spindle uses air radiation to reduce volume
- The head of the main shaft is suitable for the milling cutter specially designed for a PCB
- The rotational speeds of the main shaft can be adjusted from 2K-60K RPM according to the thickness of PCB
The screen is friendly and can be switches between Chinese and English
- Equipped with a build-in image capture, workpiece image and operation on the same screen, easy operation
- The function selection, manual function selection and instruction for shift are selected by mouse
- Mechanical parameters and function setting can be locked up with a password to avoid operation the equipment accidentally.
Value matching is accurate and instruction is conveniently
- During instructing, there are three kinds of speed optional
- Cooperating with the monitor, the diameter of a milling cutter, a circle and square frame can be set
Specification
| Model | YSATM-4L |
| Standard working area | 320*320mm |
| Power | 220V, 4.2KW |
| Manipulator Repeatability | ±0.02mm |
| Resolution | ±0.01mm |
| Board Positioning | Dual workstation with nest fixture or pin fixture |
| Panel Location | Located by tooling holes or edges of PCB |
| Loading | Manual |
| Unloading | Manual |
| Panel Size | 320*320mm(standard) |
| Panel Thickness | 0.5-3.5mm |
| Spindle motor | KAVO Spindle |
| Tool Change | Manual |
| Dust filtration system | 3KW Vacuum Cleaner |
| Vision system | High resolution CCD video camera |
| Programming | Vision assisted point to point manual teaching |
| Editing Function | Dry run vision assisted / test run mode |
| Machine weight | 500kgs |
| Machine dimension | 113*140*108cm |
Why choose us
1. Engineers available to service machinery oversea.
Engineers are available to be sent to freign countries to do machinery training and offer technical support.
2. One year warranty for the machines except accessories.
Robust frame construction and Japanese steel blades obtained good appraise and recognized by and oversea clients. We offer parts for replacement under warranty free of charge, clients only need to bear freight charge.
3..Effective customer service.
All of us together are stronger and wiser than any one of us individually. To succeed, we must assume responsibility, cooperate with fellow associates and withdepartments, effectively comminicate with one another, foster enthusiam and participate in decision-making. To be seay reachable by customers and provide prompt replies to solve their problems and create value for customers
4. Mature technique & forerunner to process makes high quality machinery.
As largest manufactory in South China, we have 12 years experience on PCB separator machines and soldering machines. pcb router machine
Our R&D team continuously upgrade the existing machines to meet the market development trend
